CW-8000 Pneumatic Stencil Cleaning Machine

Product description: CW-8000 Pneumatic Stencil Cleaning Machine
INQUIRY

CW-8000 Pneumatic Stencil Cleaning Machine Features:

1.Completely pneumatic operation without fire risk.

2.Equipment is ergonomically in designed. Cleaning and drying process can be easily control with one-button operation.

3.Special nozzle design ensures high cleaning performance. Stencil tension is not affected during the cleaning process.
4.Auto liquid feeding and draining system. The equipment is easy to operate.

5.Triplex filter system with precise exhaust design and control. Liquid can be recycled which results in lower solvent consumption

6. Internationally recognized critical components are used to ensure long term quality and reliability.

7.Modular design to ensure easy maintenance.

Pneumatic Stencil Cleaning Machine with 50L Cleaning Capacity Parameters:

Application	stencil,glue screen ,copper screen
Application stencil size	Standard 29 inch and below
Clean liquid capacity	Max 50L ,Min 20 L
Cleaning fluid volume	40L
Cleaning method	Rotary double side pressure injection and high pressure air praying ( cleaning and drying )
Clean time	2~4 min(stencil and copper net)
Rinse time	2~4 min(stencil and copper net)
Dry time	2~5 min
External air supply	0.4Mpa~0.6Mpa
Air consumption	400~600L/Min*2
Air outlet size	Φ125*25mm
Weight	320Kg
Dimension	980mm(L)700mm(W)1730mm(H)
Tin filter method	Three class filter(10μm,5μm,1μm)
