Travel range X/Y/Z (mm):

All travel can be customized

Table top load:

10KG

Moving speed mm/sec:

500

Repeat ability accuracy:

+0.03mm

Program recording capacity:

Unlimited number of files, each group 4000 points (can support U disk interface)

Display mode:

5.7 inch display screen

Motor system:

Micro stepping motor precision

Movement mode:

Point-to-point / continuous line segment

Transmission mode:

Synchronous belt + precision linear guide rail

Movement interpolation function:

3 axis (3D stereo space, any route can)

Edit mode:

Touch screen or computer file input / computer operation

I/0 signal:

16,In,puts/16,Out,puts

Control mode:

Integrated controller

Input power:

AC/220V/300W

Working environment temperature:

5-40 DEG C

Working environment humidity:

20-90%

Shape size:

(L) 700 * (W) 620 * (H) 600mm

weight (kg)

60
